Self Healing & Long Lasting Hydrophilic Coatings (Medical)

Hydrophilic coatings are under recognized but critically important when it comes to biomedical engineering. These coatings improve how medical devices work and how they interact with the body. They are used on many medical devices like catheters, implants, and biosensors.  With advancing medical technology, the need for extended coating life, and therefore extended device life becomes even more important. These coatings need to be long-lasting and self healing coatings so that they can continue to function and be resistant to problems such as biofouling (when unwanted materials stick to surfaces). This article looks at what’s next for self-healing and long-lasting hydrophilic coatings. We pay a specific focus on new materials and technologies in the space.

Understanding Hydrophilic Coatings in Biomedical Engineering ^1,2

Hydrophilic coatings are surface treatments designed to attract and hold water. These “slippery-when-wet” coatings help reduce friction, which improves patient outcomes. They also allow medical devices to work better with biological tissues. Hydrophilic coatings are widely used in medical implants, wound dressings, and drug delivery systems. This is because they can lower the risk of blood clots, bacterial growth, and inflammation. In other words, they reduce complications and improve outcomes.

Hydrogel-based coatings are made of water-absorbing polymers that imitate the extracellular matrix (the material that surrounds cells) in biological tissues. These coatings can swell and hold moisture, making them suitable for self-repairing hydrophilic coatings.

Two commons hydrogels include:

• Polyvinyl alcohol (PVA) and polyethylene glycol (PEG) hydrogels can absorb a lot of water.
• Chitosan-based hydrogels, which have antimicrobial properties, can help with both self-healing and preventing infections.

Self-Healing Mechanisms for Medical Coatings

Self-healing mechanisms help coatings extend their life. In the case of biomedical coatings, self-healing can be accomplished through different ways. These include:

1. Self-Healing via Polymer Networks with Reversible Bonds ^3,4

Self-healing coatings can use bonds that can break and reform when they get damaged. These include:

• Hydrogen bonding: These are weak but reversible bonds that can repair themselves in wet environments.
• Supramolecular interactions: These are non-covalent bonds that allow self-healing without needing any extra help.
• Dynamic covalent chemistry: These bonds can break and reform, helping coatings last longer in implants and prosthetics.

2. Self-Healing via Encapsulated Healing Agents ^1,5

Another interesting method for helping coatings self-heal is through healing agents. At a high level, this involves tiny capsules filled with healing agents inside the coatings. When the coating becomes damaged, these capsules break open and release materials that help restore the coating.

Some examples of these coatings include:

• Polydopamine-inspired coatings mimic proteins from mussels to improve self-healing.
• Chitosan-based mussel-inspired hydrogel for rapid self-healing and high adhesion of tissue adhesion and wound dressings.

Stimuli-Responsive Self-Healing Hydrophilic Coatings

Modern self-healing hydrophilic coatings can change in response to their environment.

Some examples of these include:

1. pH-Responsive Coatings ⁶

Some medical applications, such as drug delivery and wound dressings, need coatings that react to changes in pH (how acidic or basic something is).

• Polyacrylic acid (PAA)-based coatings can swell in acidic conditions to start healing processes.
• Zwitterionic materials can adjust their hydration levels based on the surrounding pH, helping to resist biofilm formation.

2. Temperature-Responsive Coatings ^7-9

Temperature-responsive hydrogel coatings are often called thermogels or thermo-sensitive hydrogels. These coatings change from a liquid to a gel when the temperature changes. One example is a chitosan-based thermosensitive hydrogel made from chitosan and β-glycerophosphate. This hydrogel has been studied for its potential use in sealing and lubricating dental implants.

At room temperature, this hydrogel stays in liquid form. But it turns into a gel at body temperature. This change helps improve the sealing and lubrication of dental implants, which can make dental prosthetics last longer and work better.

Moreover, thermoresponsive hydrogels are extensively been studied for their self-healing properties. They can also be used in other areas. These include facial masks and eye patches, showing their promise in clinical applications.

3. Light-Responsive Coatings^9,10

Light-responsive hydrogels change when light shines on them. These hydrogels are made by adding light-sensitive components to their structure.

This class of coatings ctypically release drugs in three main ways:

• Photoisomerization: This is when light causes a change in the chemical structure of the material.
• Photochemical Reaction: This happens when light starts a chemical reaction that helps release the drug.
• Photothermal Reaction: In this case, light heats the material, which helps to release the drug.

Hydrogels that contain photosensitizers (substances that help absorb light) are very important in clinical practice. Using ultraviolet (UV) light and near-infrared light, along with special particles called up-conversion nanoparticles, has improved how well these treatments work.

Currently, light-responsive drug delivery systems are being studied for their self-healing properties. They are also used to transport various kinds of drugs, proteins, and genes. They are helpful in treatments like chemotherapy, immunotherapy, photodynamic therapy, gene therapy, and wound healing, among other applications.

Electrically Conductive Hydrophilic Coatings ¹¹

Electrical conductivity is very important in biomedical applications. This is especially true in the study of nerves and heart cells (cardiomyocytes). Electroactive materials can help cells grow and develop properly.

One such material that is used is chitosan, a type of cationic polymer. Chitosan has shown great potential as a conductive material because of its natural electrical properties.

Researchers have created different types of self-healing hydrogels that are also conductive. For example, one type of self-healing hydrogel was made by combining positively charged chitosan derivatives with negatively charged acrylic acid. This combination allows the hydrogel to repair itself quickly when placed in saline solutions. Additionally, the ionic conductivity (how well electricity can flow through it) and mechanical strength (how strong it is) were improved by adding iron ions (Fe³⁺) into the chitosan-polyacrylic acid networks.

These advancements show the potential of conductive, self-healing hydrogels in biomedical engineering. This is exciting for applications that need strong and flexible materials that can conduct electricity effectively.

Long-Lasting Anti-Fouling and Anti-Biofilm Properties ^12,13

Preventing biofilm-based infections is critically important in the medical field. As a result, it is also critical to develop medical device coatings that are long-lasting and can keep bacteria from sticking. The specialized coatings make devices safer and more durable. They enhance how well the devices interact with the body and decrease how easily bacteria can stick to them.

One of the most significant aspects of these coatings is that they form a hydrophilic (water-attracting) surface. This allows water to flow easier across the surface. This minimizes how much protein adheres to the surface.

Why is this important?

It is significant because a hydrophilic surface can prevent bacteria from adhering initially. And this leads to less biofilm formation. For instance, smart lubricant coatings (made of polyurethane and polyvinylpyrrolidone), are effective in avoiding infection associated with ureteral stents due to their hydrophilic character.

Studies on coatings from polymeric nanofibers have shown new systems that are capable of regulating the delivery of antibiotics. The systems seek to release antimicrobial agents at an early stage of biofilm formation. This enhances the effectiveness of the coatings and reduces the likelihood of implant failure. The performance of medical devices can be enhanced by integrating hydrophilic, antimicrobial, and anti-biofilm properties in the coatings. As a result they are a potential solution for maintaining the longevity of implants.

Hydromer™ Inc. – Your Partner for Self-Healing and Long-Lasting Hydrophilic Coatings for Biomedical Applications

Hydromer Inc. is a leading manufacturer of custom hydrophilic coatings and hydrogels used in the medical field.

Self-healing coatings are a new area of research in medicine. These surfaces can fix themselves when damaged using special properties like reversible physical or chemical bonds. But while these possibilities are exciting they can also seem daunting. But that is where Hydromer’s contract R&D services can help you develop advanced medical devices that set your company apart. So if your company is interested in adding self-healing functionality to your medical devices contact Hydromer to start your R&D project now.

Conclusion

Self-healing and long-lasting coatings are exciting new developments in biomedical engineering. These coatings help solve problems like biofouling, mechanical wear and tear, and the short lifespan of medical devices. Scientists are creating coatings that can repair themselves, adjust to their surroundings, and last longer.

References

1. Yang Y, Ma Y, Wang J, et al. Chitosan-based mussel-inspired hydrogel for rapid self-healing and high adhesion of tissue adhesion and wound dressings. Carbohydrate Polymers. 2023/09/15/ 2023;316:121083. doi:https://doi.org/10.1016/j.carbpol.2023.121083
2. Thai NLB, Beaman HT, Perlman M, Obeng EE, Du C, Monroe MBB. Chitosan Poly(vinyl alcohol) Methacrylate Hydrogels for Tissue Engineering Scaffolds. ACS Applied Bio Materials. 2024/12/16 2024;7(12):7818-7827. doi:10.1021/acsabm.3c01209
3. Yang Y, Liu S, Cai X, Ma D, Xu J. Supramolecular hydrogel containing multi-generation poly(L-lysine) dendrons for sustained co-delivery of docetaxel and matrix metallopeptidase-9 short hairpin RNA plasmid. Journal of Bioactive and Compatible Polymers. 2020/01/01 2019;35(1):3-23. doi:10.1177/0883911519894683
4. Ajdnik U, Luxbacher T, Vesel A, et al. Polysaccharide-Based Bilayer Coatings for Biofilm-Inhibiting Surfaces of Medical Devices. Materials (Basel, Switzerland). Aug 21 2021;14(16)doi:10.3390/ma14164720
5. Qian B, Zheng Z, Michailids M, et al. Mussel-Inspired Self-Healing Coatings Based on Polydopamine-Coated Nanocontainers for Corrosion Protection. ACS Applied Materials & Interfaces. 2019/03/13 2019;11(10):10283-10291. doi:10.1021/acsami.8b21197
6. Quan L, Tie J, Wang Y, et al. Mussel-inspired chitosan-based hydrogel sensor with pH-responsive and adjustable adhesion, toughness and self-healing capability. Polymers for Advanced Technologies. 2022/06/01 2022;33(6):1867-1880. doi:https://doi.org/10.1002/pat.5643
7. Cao X, Cai X, Chen R, Zhang H, Jiang T, Wang Y. A thermosensitive chitosan-based hydrogel for sealing and lubricating purposes in dental implant system. Clinical implant dentistry and related research. Apr 2019;21(2):324-335. doi:10.1111/cid.12738
8. Quattrone A, Czajka A, Sibilla S. Thermosensitive Hydrogel Mask Significantly Improves Skin Moisture and Skin Tone; Bilateral Clinical Trial. Cosmetics. 2017;4(2). doi:10.3390/cosmetics4020017
9. Pang Y, Wei C, Li R, et al. Photothermal conversion hydrogel based mini-eye patch for relieving dry eye with long-term use of the light-emitting screen. International journal of nanomedicine. 2019;14:5125-5133. doi:10.2147/ijn.s192407
10. Xing Y, Zeng B, Yang W. Light responsive hydrogels for controlled drug delivery. Frontiers in bioengineering and biotechnology. 2022;10:1075670.
11. Ou Y, Tian M. Advances in multifunctional chitosan-based self-healing hydrogels for biomedical applications. Journal of Materials Chemistry B. 2021;9(38):7955-7971.
12. Li K, Tang H, Peng J, et al. Smart Lubricant Coating with Urease-Responsive Antibacterial Functions for Ureteral Stents to Inhibit Infectious Encrustation. Advanced Functional Materials. 2024/01/01 2024;34(2):2307760. doi:https://doi.org/10.1002/adfm.202307760
13. Ashbaugh AG, Jiang X, Zheng J, et al. Polymeric nanofiber coating with tunable combinatorial antibiotic delivery prevents biofilm-associated infection in vivo. Proceedings of the National Academy of Sciences of the United States of America. Nov 8 2016;113(45):E6919-E6928. doi:10.1073/pnas.1613722113
